What is the main component of the automotive auxiliary dashboard?
"Automobile auxiliary dashboard" usually refers to the sub-IP (central console), and its main components include: the main frame (molded/foamed structure), the armrest assembly, the shift/brake control panel, the cup holder/storage box, the air outlet module and the integrated control panel (such as air conditioning/ electronic gearshift/ touch screen, etc.).
Main frame: The basic structure that supports the entire sub-IP, mostly made of hard plastic or foamed material and molded.
Armrest assembly: Includes the surface material (leather/soft plastic) and internal support, providing support for the driver's arm.
Control panel area: Covers the shift lever, electronic handbrake, start button, driving mode knob, etc., and is a decorative and protective cover.
Integrated components: Such as wireless charging board, USB interface, small storage compartment, ashtray (for some models);
Air outlet and duct: Usually integrated on the upper part of the sub-IP, serving the front passengers;
Cable and brackets: Supporting the internal electrical components (such as display screens, sensors) and connecting the vehicle's circuitry.
Note: "Auxiliary dashboard" is not a standard term. If referring to the auxiliary display module of the main dashboard (driver's front dashboard) (such as HUD, passenger-side screen), the main components are the display module, PCB circuit board, housing and brackets; but according to industry practice, "auxiliary dashboard" mostly refers to the sub-IP. If the intended meaning is the main dashboard (combination of gauges), the core is the dashboard cover, base shell, circuit board (including MCU/stepper motor), indicator lights/display.
"Automobile auxiliary dashboard" usually refers to the sub-IP (center console / sub-IP), and its main components mainly undertake functional integration, control support and improvement of safety and comfort, rather than directly displaying core driving parameters (that is the responsibility of the main dashboard).
Integrated control functions: Centralized arrangement of air conditioning panel, multimedia knobs/touch areas, driving mode selection, electronic handbrake, automatic parking, steep slope descent, etc., reducing driver distraction.
Provide storage and human-machine support: Including cup holder, wireless charging for mobile phones, storage box, shift area (including P/R/N/D gears), and as an armrest support to enhance operational comfort.
Safety and structural functions: Some sub-IP bodies are connected to the vehicle's frame and participate in collision energy management (such as side impact energy absorption), and hide cables/air conditioning pipes, taking into account stiffness and collapse design.
Decoration and atmosphere creation: Through materials (soft padding, wood grain, metal trim) and lighting (atmospheric light strips) to enhance interior quality, and together with the main dashboard to form the vehicle's cabin style.
Please note: "Auxiliary dashboard" is not a standard term. The industry usually distinguishes between the main dashboard (driver's front, including core displays such as speed/rpm) and the sub-IP (central console to the front seats, focusing on control and storage). If referring to the "auxiliary display components" of the main dashboard (such as HUD, small screen indicator lights), the role is to supplement key information and reduce gaze deviation, but the main components are still taken by the main dashboard.
"Faults of the main dashboard's auxiliary dashboard components" usually refer to hardware/communication abnormalities of the combination gauge (including main display, pointers, indicator lights and internal circuit board) or its associated driving assistance system (such as front radar, camera, control unit), which need to be determined based on specific fault codes and symptoms.
Common causes: Fuse melting, loose/corrosive plugs, poor power supply/grounding, sensor (such as speed, radar) failure, CAN bus communication interruption (such as HS2CAN), internal PCB cracking or LCD screen driver chip failure, or software false alarm. If there is a prompt such as "Front auxiliary function unavailable" or related to auxiliary functions: This is mostly due to the radar/camera being blocked, damaged, not calibrated, or the control module losing communication. It is not an issue with the instrument itself; first, clean the sensor, remove any added components, and restart the vehicle. If it doesn't work, read the fault codes.
If the instrument screen goes black, the pointers don't move, and multiple lights are constantly on: Focus on checking the instrument power supply fuse (usually in the engine compartment or the driver's side fuse box), whether the connectors are loose, and whether the grounding points are rusted. If necessary, use a multimeter to measure the voltage. If everything is normal, the combined instrument assembly may have internal damage and needs to be replaced or professionally repaired.
Do not disassemble the instrument yourself: Modern instruments integrate EEPROM (for storing mileage, anti-theft data), and replacing them randomly can result in information loss or system locking. It should be handled precisely by a repair station using a diagnostic tool (such as ISTA, X431) to read the codes.
Emergency handling: If there is only occasional prompts (such as disappearing after a few seconds of startup), it may be due to a momentary voltage fluctuation; if accompanied by power limitations, brake/steering warning lights constantly on, immediately stop for inspection.
Suggestion: Connect an OBD diagnostic tool as soon as possible to read the specific fault codes (such as U0423 invalid data, B1204 instrument communication failure, etc.). Different codes correspond to different modules (sensors, gateway, instrument motherboard). Avoid replacing components blindly. If no tools are available, go to a brand 4S store or a professional electronic control repair shop for testing.
