What is the rear door frame protection device for the car?
The rear door frame protection device refers to the key component installed inside the rear door structure and used to enhance the side impact safety. According to public information, these devices mainly have the following forms and functions:
Door impact beam (side door impact bar)
This is the core "rear door frame protection device" and is an important part of the passive safety system.
Location: Hidden between the inner and outer panels of the rear door, not visible from the outside.
Structural type:
Cylindrical: Such as round tubes and rectangular tubes, commonly seen in Japanese and Korean models.
Cap-shaped: Such as U-shaped or M-shaped (double caps), more common in European and American models, with better energy absorption effect.
Material strength:
Common high-strength steel: Tensile strength of 1000–1600 MPa.
High-end models have adopted 2000 MPa or even 2400 MPa (2.4 GPa) hot-formed steel, significantly enhancing the anti-deformation ability.
Function:
Absorb and disperse impact energy during side collisions.
Reduce the intrusion of the door (measured to reduce by more than 45%).
Protect key parts such as the driver's legs and pelvis.
Note: Some models (such as Honda CR-V) to control costs, the rear door may only have a single impact beam, while the front door is equipped with a more complex structure.
Door edge impact strip (non-load-bearing structure)
Although the name contains "impact protection", it does not belong to the frame protection device, but an exterior component:
Material: TPU or high-rebound PVC.
Function: Prevent damage to the paint surface or edge sheet metal caused by low-speed scratches (such as when the neighboring vehicle opens the door).
Characteristics: Replaceable, seamless installation, not involved in the force of the vehicle body structure.
Impact beam of the rear door and vehicle safety coordination
The rear door impact beam needs to be combined with the B-pillar, beam， and roof longitudinal beam， etc.， to form a side protection network to ensure the effective transmission of collision force.
The layout height is usually 300–500mm from the ground， matching the side impact test standards of C-NCAP， etc. Summary
The true "door frame protection device" is the anti-collision beam (anti-collision bar) inside the door, which is a high-strength structural component.
The "door anti-collision strips" available on the market are merely decorative/buffering accessories and do not possess the passive safety function of the anti-collision beam.
If you are concerned about vehicle safety, it is recommended to consult the specific model's collision test report (such as C-NCAP or IIHS) to confirm whether an anti-collision beam is equipped and its material grade.
The rear door frame protection device of a car usually refers to the anti-collision beam (also known as the side door anti-collision rod or side impact beam), which is installed inside the door and is a key passive safety component for enhancing side collision safety. Its functions can be summarized as follows: Core function
Absorbing and Distributing Impact Energy: During a side collision, the impact bar deforms through its own structure to absorb the impact force, reducing the deformation of the door inward, thereby minimizing direct injury to the occupants.
Protecting Passenger Safety: Especially when the vehicle collides with fixed objects such as trees or utility poles, it significantly enhances the survival space and ensures the safety of passengers.
Maintaining the Integrity of Door Structure: Preventing the failure of key components such as the door lock mechanism and windows due to the collision, ensuring that the door can still be opened normally after the collision, facilitating escape or rescue.
Structural and Design Features
Installation Position: Located between the inner and outer panels of the door, invisible from the outside.
Common Structural Forms:
Tubular: Such as round tubes and rectangular tubes, commonly seen in Japanese and Korean models;
Cap-shaped: Such as U-shaped and M-shaped (double caps), mainstream in European and American models, with better energy absorption effect.
Arrangement Method: Including vertical, diagonal (Y-shaped), etc. Some models adopt a front-high and rear-low design to optimize the energy transfer path.
Material Strength: Traditional high-strength steel has an tensile strength of 1400–1600 MPa; since 2026, 2.4GPa hot-formed steel has been widely applied, with strength increased by over 20%. Actual effect
According to statistics from the US NHTSA, the door impact beams saved 994 accident victims in 2002.
The double cap structure can reduce the door intrusion by approximately 40%.
Note: For some models (such as Honda CR-V), to control costs, the rear doors only have a single tube-shaped beam, without the cap-shaped reinforcement ribs like those on the front doors, resulting in a relatively lower level of protection.
