What is the core of a car thermostat
The core of the automotive thermostat, also known as the temperature-sensing element or thermal core, is the core component inside the thermostat. It is responsible for sensing the temperature of the coolant and driving the valve to open and close, thereby automatically adjusting the circulation path of the coolant.
The structure and working principle of the thermostat core are based on the principle of thermal expansion and contraction. Youdaoplaceholder1 its interior is usually filled with paraffin (sometimes copper powder is added to improve thermal conductivity). When the coolant temperature is low, the paraffin is in a solid state, the valve remains closed under the action of the spring, and the coolant quickly preheats the engine through a small circulation (only flowing inside the engine). When the temperature rises to a specific threshold (typically 75°C to 105°C, common values include 82°C to 88°C), the paraffin melts and expands, pushing the metal push rod or valve disc to open the valve, allowing the coolant to flow into the radiator for a large circulation to enhance heat dissipation.
The performance of the thermostat core directly affects the operating temperature of the engine. If fails (such as paraffin loss or deterioration), it may cause the valve to fail to open or close normally, leading to problems such as engine overheating or excessive preheating time. Modern electronic thermostats replace paraffin with electric heating elements to achieve more precise temperature control.
The core of a car thermostat (usually referring to the temperature-sensing element in the thermostat, such as a paraffin capsule) is the core component of the thermostat. Its function is to automatically control the on/off of the coolant circulation path based on the change in coolant temperature, thereby regulating the engine's heat dissipation capacity and ensuring that the engine operates within the optimal temperature range (typically 80-95℃).
The thermostat core achieves automatic regulation through the physical properties of the temperature-sensing material: when the engine is cold-started, the coolant temperature is relatively low, and the temperature-sensing element (such as paraffin) is in a solid state, pushing the valve to close the passage to the radiator, allowing the coolant to circulate only within the engine for a small period, rapidly raising the temperature. When the coolant reaches the set value (such as around 80℃), the temperature-sensing element melts and expands due to heat, pressing the rubber hose or push rod to open the valve. The coolant then flows through the radiator for a large circulation to cool down, preventing the engine from overheating.
Youdaoplaceholder0 this automatic regulation process has an important influence on engine performance:
Youdaoplaceholder0 Enhance efficiency and economy : When the engine operates at an appropriate temperature, fuel burns more fully, reducing fuel consumption by 10% to 15%, and minimizing the erosion of cylinder walls by carbon deposits and unburned fuel.
Youdaoplaceholder0 Reduce wear and extend service life : Avoid the increase in frictional resistance caused by the increase in lubricating oil viscosity at low temperatures, and reduce the wear of components such as crankshafts and bearing shells.
Youdaoplaceholder0 Stable power output : Prevent poor atomization of fuel when the temperature is too low to ensure smooth power.
The reliability of the thermostat core is directly related to the stability of the thermal management system. If it malfunctions, it may cause the engine to remain at a low temperature or overheat for a long time, exacerbating fuel consumption and wear problems.
The thermostat core is a key component in the automotive cooling system, responsible for automatically adjusting the coolant circulation path based on the engine temperature to maintain the engine at the optimal operating temperature (typically 80-90℃).
1
Its malfunction will trigger a series of chain problems, affecting the performance and lifespan of the engine.
The main causes of the thermostat core failure include: the opening temperature of the valve is too high or it cannot be opened, which leads to the coolant being unable to complete the large circulation and causes the engine to overheat; If it is not closed tightly, the engine will heat up slowly or become too cold. Long-term use of unclean coolant may lead to valve corrosion, scale accumulation or impurity blockage. Leakage of the internal temperature-sensing wax bag, failure of the spring or rust and adhesion can also disrupt its normal function.
The main symptoms of fault are:
Youdaoplaceholder0 Abnormal water temperature : When the thermostat gets stuck and closes, the engine is prone to overheating and the water temperature alarm light will come on. If the main valve does not close tightly, the water temperature will rise slowly and the engine will operate at a low temperature for a long time.
Youdaoplaceholder0 Fuel consumption and performance decline : Both overheating and overcooling can reduce combustion efficiency, increase fuel consumption, and may cause carbon deposits due to incomplete fuel combustion, leading to engine shaking, reduced power or difficulty in starting.
Youdaoplaceholder0 Abnormal cooling system : The fan may not start as needed, or the water circulation is unstable, for example, there is water flowing in the inlet pipe too early during cold start or no water flow after high temperature.
Youdaoplaceholder0 The following methods can be used to determine the fault of the thermostat core:
Youdaoplaceholder0 Feel test : After starting the engine, touch the upper and lower water pipes of the radiator for about 3 minutes. Under normal circumstances, the upper pipe is hot and the lower pipe is cool. If the temperature difference between the two is small or they are hot at the same time, a malfunction may occur.
Youdaoplaceholder0 Water flow observation : When starting cold, observe the water inlet pipe of the water tank. If there is a continuous water flow when the water temperature is below 70℃, it indicates that the main valve is not closed tightly. If there is still no water flow after the water temperature exceeds 90℃, it may be stuck and shut off.
Youdaoplaceholder0 infrared temperature measurement : Measure the inlet and outlet water temperatures of the thermostat. Under normal circumstances, when the water temperature reaches around 70℃, the outlet water temperature should suddenly rise. If the temperature difference remains large or does not change at all, it may fail.
Youdaoplaceholder0 Disassembly and heating test : Immerse the thermostat in water for heating. It should be turned on at 75℃, and the lift should be greater than 8.5mm at 93℃; otherwise, it needs to be replaced.
Youdaoplaceholder0 Handling and preventive measures include: If the fault is confirmed, the thermostat should be replaced in time. The cost at a regular repair shop is about 100 to 300 yuan, while the cost at a 4S store is relatively high. After replacement, be sure to exhaust all the air in the cooling system and check the quality of the coolant. If it is turbid or contains many impurities, it should be replaced simultaneously. During daily maintenance, regularly checking the coolant level, freezing point and cleanliness, and using qualified antifreeze can reduce the probability of thermostat failure.
