The function of the car's heating water tank
The automotive heating water box is the core component of the vehicle's thermal management system. Its main function is to utilize the residual heat from the engine to provide warmth inside the vehicle and ensure driving safety. The working principle is to circulate the engine coolant, transfer the heat to the air, and then the blower sends the warm air into the cabin.
Core function
Provide heating inside the vehicle: The heating water box is the core of the vehicle's heating system. When the engine is running, the coolant is heated to around 90°C and flows through the heating water box. The blower blows cold air over the heated pipes, causing the air to heat up, thereby providing warmth to the cabin and enhancing the comfort of passengers. This is a form of waste heat recovery, requiring no additional fuel consumption, and is energy-efficient and environmentally friendly.
Quick deicing and dehumidification, ensuring driving safety: In cold or humid weather, the heating water box can effectively heat the front windshield and side windows, quickly eliminating frost and fog. Test data shows that after 5 minutes of opening the heating, the average temperature of the front windshield increases by 8-12°C, eliminating over 80% of the frost and fog. It is recommended to set the temperature at 22-24°C and select the "front windshield + foot" ventilation mode, which can ensure clear vision and enhance foot comfort.
Assist in maintaining the normal operating temperature of the engine: The heating water box does not work independently; it participates in the heat exchange cycle of the engine cooling system. When the engine load is high and the temperature is high, the heating water box can assist the radiator in heat exchange, helping to disperse heat and prevent localized overheating of the engine, thereby maintaining the stable performance and lifespan of the engine.
Usage and maintenance suggestions
Use reasonably: After cold start, it is recommended to wait for the water temperature to rise to around 90°C before turning on the heating. At this time, the heating effect is better, and energy consumption is reduced. Set the outlet fan downward to facilitate warm air convection, making the cabin temperature more uniform.
Regular maintenance: It is recommended to replace the dedicated coolant (antifreeze) every 2 years or 40,000 kilometers to prevent the accumulation of scale and impurities that may cause the heating water box to clog or corrode. Daily checks are required for the coolant level, ensuring it is between the MIN and MAX marks.
In summary, the heating water box is a "wonder device" for winter driving. It converts engine waste heat into comfort and safety, and is an indispensable important component in modern vehicles.
When the heating water box is damaged, the main phenomena include:
Heating failure or insufficient temperature: After turning on the heating, the outlet fan continues to blow cold air or the temperature is too low, even if the engine water temperature is normal, it cannot be improved.
Abnormal coolant consumption or leakage:
The coolant level drops rapidly, requiring frequent coolant replenishment.
Pale pink/green liquid traces appear near the chassis or engine compartment (antifreeze).
Fogging and odor inside the cabin:
The front windshield frequently fogs up and is difficult to clear.
The cabin emits a sweet smell (caused by the evaporation of coolant).
Increased engine water temperature: The temperature gauge on the dashboard rises abnormally, possibly triggering a high-temperature alarm.
Abnormal noise: Water-like sounds or gurgling sounds are heard from the center console, more noticeable at idle.
Unstable vehicle speed: Engine power output fluctuates, affecting the smoothness of driving.
