What material is the car radiator made of?
Common materials for car radiators include aluminium alloy, copper, and plastic. Among them, aluminium alloy is the mainstream choice due to its lightweight, high thermal conductivity, and cost advantage. Here is a detailed description:
Aluminium alloy: Lightweight, good thermal conductivity, and strong corrosion resistance. It is widely used in modern car cooling systems, especially replacing copper as the mainstream material.
Copper: Excellent heat dissipation performance but high cost and subject to price fluctuations. It is gradually being replaced by aluminium alloy, and some trucks are still using it.
Plastic: Lightweight, low cost, and corrosion-resistant. However, it has poor thermal conductivity and is prone to deformation at high temperatures. It is mostly used in the water tank storage part of small cars.
To determine if the car radiator needs to be replaced, you can start from the following aspects:
Appearance inspection
Color change: The original factory radiator surface is pure black. If the surface is slightly yellowish, it indicates aging and requires timely replacement.
Interface area: Check if the water pipe at the interface of the radiator is yellowish and prone to cracking. If such situations occur, it may require replacement.
Rust and scratches: A new radiator surface is smooth and flat, without rust, scratches, or dents; an old radiator may have wear marks, especially at the edges and corners.
Markings and labels: A new radiator has clear brand markings, model, and production date; an old radiator has blurry markings and irregular labels.
Water temperature and coolant status
Water temperature gauge pointer: During normal driving, the water temperature gauge pointer rises rapidly, or the water temperature warning light comes on, indicating a problem with the radiator's heat dissipation.
Coolant level: The coolant level has significantly decreased and there is no external leakage, possibly indicating internal leakage.
Coolant clarity: Antifreeze is usually transparent and free of impurities. If it is found to be cloudy, it may affect the cooling performance.
Coolant odor: Fresh antifreeze has a pleasant fragrance; if an acidic smell is detected, it indicates that it has lost its effectiveness.
Running sound and engine condition
Running sound: After starting the vehicle, abnormal water flow sound or gurgling sound is heard from the engine compartment, which may indicate a radiator fault.
Engine condition: When the radiator fails, the engine may experience power loss, shaking, or sudden engine shutdown due to overheating.
Maintenance records
Maintenance records: Check the vehicle's maintenance records. If the records show that the radiator has been replaced, it can be confirmed.
Seasonal factors
Antifreeze selection: If using summer antifreeze in cold seasons, it may freeze due to insufficient freezing point, affecting cooling efficiency. It is necessary to replace with winter antifreeze in time.
Other signs
Coolant leakage: Frequent reduction of coolant or obvious leakage signs indicate a need to consider replacing the radiator.
Cracks and deformation: Check if the radiator has cracks, deformation, or corrosion.
Summary: To determine if the car radiator needs to be replaced, it is necessary to consider multiple aspects such as appearance, water temperature, coolant status, running sound, maintenance records, and seasonal factors. If any of the above abnormalities are found, it is recommended to promptly take the vehicle to a professional repair shop for inspection and repair to ensure driving safety.
Car radiator failures can indeed directly affect driving safety. Let me help you summarize the common problems and solutions:
Cooling system failure
Insufficient coolant or leakage
The coolant level is below the MIN line or the radiator is wet around the edges, which may indicate a cracked water pipe, loose radiator cap, or leaking rubber hose connection.
Emergency treatment: Add pure water as a temporary solution, but a long-term solution requires using dedicated coolant; inspect the radiator, water pump interface, and rubber piping.
Thermostat stuck
After cold start, the temperature difference between the upper and lower pipes of the radiator is significant, preventing the coolant from circulating.
Solution: Replace the thermostat, and for vehicles over 100,000 kilometers, it is recommended to regularly check the condition of the water pump.
Circulation system failure
Water pump failure
Loose or broken belt or detached impeller, preventing the coolant from circulating.
Check points: Observe if the water pump belt is intact and if the impeller is detached. Water tank clogged
Lint and dust clog the surface of the radiator, or internal scale deposits affect the heat dissipation efficiency.
Handling method: In an emergency, use a low-pressure water gun to rinse the surface of the radiator. Internal blockage requires professional cleaning or replacement.
Reduced heat dissipation efficiency
Bursting of water tank heat dissipation pipe
In high-temperature conditions, the water tank may burst due to inability to withstand the pressure.
Emergency handling: Add leak stopper to the water tank, start the car, then cut and seal the leaking heat dissipation pipe.
Long-term heavy load or idling with air conditioning on
The engine load is too high. It is recommended to stop the vehicle for ten minutes to cool down every two hours in hot weather.
Common other faults
Water tank cover not tightened
Causes coolant leakage and a drop in liquid level.
Solution method: Check and secure the water tank cover tightly.
Leaking due to emulsified engine oil
The emulsification of engine oil indicates cylinder erosion or wear. It is necessary to disassemble the engine and replace the cylinder gasket.
Bursting of water tank heat dissipation pipe
Add a leak stopper to the water tank, start the car, then cut and seal the leaking heat dissipation pipe.
Fault symptoms
Excessive engine water temperature
The water temperature gauge pointer rises rapidly to the high "H" mark position, and the overheating warning light comes on.
Coolant leakage
Green, blue or pink coolant droplets fall from the bottom of the car or the engine compartment.
Decreased car performance
Slow acceleration, abnormal engine vibration, seriously affecting driving experience and engine lifespan.
Air escaping from water tank cover
When coolant is insufficient, air escaping from the water tank cover occurs. This is caused by pressure changes inside the water tank.
Emergency handling and preventive measures
When the instrument water temperature alarm sounds
Immediately turn on the heater (auxiliary cooling), pull over to the side and turn off the engine.
Daily maintenance
Replace the antifreeze every 20,000 kilometers or one year. Avoid adding tap water.
Regularly check if there is any leakage or rust in the water tank. Clean, replace or add antifreeze on time.
If you want to know more, keep reading the other articles on this site!
