The working principle of the front brake pads of a car
The working principle of the front brake pads in a car is to convert the kinetic energy of the vehicle into heat energy through friction, thereby achieving deceleration or stopping. Its operation process relies on the synergy of the hydraulic system and the friction materials.
When the driver steps on the brake pedal, the pedal force is amplified by the vacuum booster, which then drives the master cylinder to generate hydraulic pressure. This pressure is transmitted through the brake lines to the brake calipers of the front wheels, where the pistons inside the calipers press the front brake pads against the rotating brake discs (discs). The friction material on the surface of the brake pads undergoes intense friction with the brake discs, generating a powerful braking torque, which reduces the rotational speed of the wheels and ultimately achieves vehicle deceleration or stopping. During this process, the vehicle's kinetic energy is converted into heat energy, which is dissipated into the air through the heat dissipation structures of the brake discs and brake pads.
The front brake pads bear the main braking force in the braking system. Due to the forward movement of the vehicle's center of gravity during braking, the front wheels typically bear more than 70% of the braking force. Therefore, the wear rate of the front brake pads is usually faster than that of the rear brake pads, and their design pays more attention to wear resistance and heat dissipation performance to cope with the high temperatures generated during high-speed braking. The front brake pads are mostly made of high-performance friction materials such as ceramics, semi-metals, or NAO to ensure a stable friction coefficient and braking effect at high temperatures.
In addition, modern vehicles often have ventilated or perforated brake discs to enhance heat dissipation efficiency and prevent "brake fade" caused by overheating, ensuring driving safety.
The damage of the front brake pads in a car is a safety issue that requires immediate attention, as it directly affects the braking performance and handling stability of the vehicle. The following are the typical symptoms that may occur when the front brake pads are damaged:
Sharp abnormal noise during braking: such as continuous "screaming" or "metal friction" sounds, which is a clear signal that the brake pads have reached the limit of wear and the metal backing plate has begun to directly contact the brake disc.
Vibration of the brake pedal or steering wheel: when braking, you can feel a significant vibration in the brake pedal or steering wheel, which often indicates that the brake disc has deformed due to uneven wear or overheating, and the abnormal wear of the brake pads is the common cause of this problem.
Increased braking distance and lack of braking power: it takes deeper pedal pressure to achieve the expected deceleration effect, and the vehicle responds slowly, which is a direct manifestation of the loss of braking force due to the wear of the brake pad friction material.
Abnormal smell: during driving, a smell similar to burning or chemical burning is detected, indicating that the brake pads have undergone ablation due to excessive friction or high temperatures.
Brake system warning light on the dashboard: some models are equipped with brake pad wear sensors, and when the wear reaches the limit, the brake system warning light on the dashboard will automatically illuminate.
Important reminder: The front brake pads bear most of the braking force of the vehicle, and their damage significantly increases the braking distance and is highly likely to cause a serious accident. Please immediately stop driving at high speed and in emergency braking, and promptly take the vehicle to a professional repair shop for a comprehensive inspection.
Maintenance suggestions:
Must be replaced: Brake pads are wear-prone parts. Once damaged or worn to the limit, they cannot be repaired and must be replaced with new parts.
It is strongly recommended to replace both front brake pads at the same time: even if only one front brake pad is damaged, it is strongly recommended to replace both the left and right front brake pads simultaneously to ensure balanced braking force and prevent the vehicle from veering during braking.
Check related components: When replacing the brake pads, check if the brake disc is worn, deformed or cracked, and if the brake calipers, brake oil lines, etc. are normal. Replace or repair them if necessary.
Choose official parts: Brake pads are related to life safety. It is essential to choose official brands and parts that meet the original factory specifications to avoid using inferior products for cost savings.
