What is a valve in an automotive air conditioning heat pump system
One of the core components of an automotive air conditioning heat pump system is the four-way directional control valve (also known as the four-way valve), which is a key device for switching between cooling and heating modes.
The function and structure of the four-way valve
The four-way valve controls the movement of the slider through an electromagnetic coil to change the flow path of the refrigerant.
Youdaoplaceholder0 Refrigeration mode : The slider moves to the left, connecting the compressor outlet to the indoor heat exchanger (evaporator) and the inlet to the outdoor heat exchanger (condenser), with the outdoor heat exchanger serving as the condenser for heat dissipation.
Youdaoplaceholder0 Heating mode : the slider moves to the right. The compressor outlet is connected to the outdoor heat exchanger, and the inlet is connected to the indoor heat exchanger. The indoor heat exchanger serves as a condenser to release heat, while the outdoor heat exchanger absorbs ambient heat.
Key technical features
The flow direction of the refrigerant is controlled by an electromagnetic guide valve to achieve rapid mode switching.
By using reverse cycle heating (consuming a small amount of electrical energy to transfer a large amount of heat), the heating efficiency in winter can be improved.
It needs to work in coordination with components such as electric compressors and electronic expansion valves to form a complete heat pump system.
The major domestic suppliers include Sanhua Intelligent Control, Yilun Co., Ltd. and other enterprises.
The valve of the automotive air conditioning heat pump system (usually referring to the four-way valve) is a key component for switching between cooling and heating modes, achieving two working modes by changing the flow direction of the refrigerant.
Refrigeration mode
After the four-way valve is powered on, it switches to the AD connected and BC connected states. The refrigerant circulates through the compressor → condenser → expansion valve → evaporator → compressor to achieve cooling inside the vehicle.
Heating mode
After the four-way valve is de-energized, it switches to the AD connected and BC connected states. The refrigerant circulates through the compressor → cooler → expansion valve → condenser → compressor, heating the air inside the vehicle by absorbing heat from outside.
This valve also has a function to protect the compressor: it automatically closes the valve when the pipeline pressure is abnormal to prevent the compressor from being overloaded and damaged.
Valve failure in the automotive air conditioning heat pump system may manifest as the following symptoms:
The cooling/heating effect has declined
When the valves of the heat pump system (such as four-way valves or solenoid valves) malfunction, it may cause abnormal flow of the refrigerant, directly affecting the cooling or heating efficiency. For instance, a stuck four-way valve can cause the heating efficiency to drop by more than three times, while a malfunction of the solenoid valve may lead to unstable cold air flow or abnormal operation of the compressor.
The system protection mechanism has been triggered
Faults may trigger the self-protection mechanism of the air conditioning system, such as the compressor automatically shutting down due to excessive pressure, or the system automatically shutting down due to overheat protection.
Abnormal sounds and increased energy consumption
If the valve control is abnormal, problems such as abnormal noise from the compressor and excessive current may occur, leading to increased energy consumption (such as reduced range of new energy vehicles) or decreased battery cooling efficiency.
Maintenance suggestions
It is recommended to give priority to checking the power connection, refrigerant leakage or valve jamming issues. If the solenoid valve is faulty, it is necessary to check whether the valve core is stuck or oxidized. If necessary, the valve assembly should be replaced.
The damage of the valve in the car air conditioning heat pump system can lead to abnormal cooling/heating effects. The specific manifestations and maintenance suggestions are as follows:
Common fault manifestations
Poor cooling/heating effect : If the valve is stuck or damaged, it may cause abnormal flow of the refrigerant, affecting the normal circulation of the system and resulting in insufficient cold and heat output.
Youdaoplaceholder0 sometimes cold and sometimes hot : When the valve control logic is abnormal, intermittent cooling/heating faults may occur. For example, it can be temporarily restored after closing the AC switch and restarting.
Youdaoplaceholder0 System pressure anomaly : Valve failure may cause pressure fluctuations on the high and low pressure sides, resulting in abnormal data flow.
Maintenance suggestions
Youdaoplaceholder0 Check the valve status : If a valve fault is suspected, the pressure data and the movement status of the valve needle can be detected by professional equipment to confirm whether it is stuck or damaged.
Youdaoplaceholder0 Replace parts : If it is a mechanical valve (such as a variable displacement valve), the original factory or compatible parts need to be replaced (for example, the variable displacement valve needs to be replaced for the Focus model); If it is an electromagnetic valve, a replacement part corresponding to the control logic needs to be matched.
Youdaoplaceholder0 System matching and debugging : After replacement, the system pressure parameters need to be reset to ensure that the refrigerant charge matches the valve.
It is recommended to contact a professional maintenance institution to detect the specific cause of the fault to avoid secondary damage caused by self-disassembly.
