What is a rear fog lamp
Detailed analysis of the rear fog lights
Youdaoplaceholder0 Definition and Function
Rear fog lights are specialized lighting devices at the rear of a vehicle. Their main function is to enhance driving safety by giving a strong red light signal when visibility is greatly affected by weather conditions such as fog, rain, snow or dust. Its luminous intensity is significantly higher than that of ordinary taillights, and it has stronger penetration.
Youdaoplaceholder0 Location and design
It is usually installed on both sides of the rear of the vehicle, or if there is only one, on the left side of the direction of travel of , at a height of 250mm to 1000mm from the ground.
The lampshade and the light source are red, which is convenient to distinguish from other lights (such as brake lights).
Youdaoplaceholder0 Regulations and usage guidelines
In most countries, rear fog lights are mandatory to install to ensure safety in low visibility conditions.
Note when in use: turn on only when visibility is lower than good to avoid strong light interfering with other drivers' vision.
Youdaoplaceholder0 Switch mode
The switch designs of the rear fog lights are diverse, including knob type, pull type or tap type, depending on the vehicle model.
The difference from other lights
Rear fog lights are different from regular taillights or brake lights. They are brighter and designed for bad weather , while taillights are mainly used for position indication during daily driving.
Rear fog lights are dedicated lighting devices at the rear of a vehicle. Their core function is to enhance the vehicle's visibility in bad weather or special environments through highly penetrating red light. Specific functions include:
Youdaoplaceholder0 Enhance distinctiveness and alertness
Under low visibility conditions such as fog, snow, rain and sandstorms (usually when visibility is less than 100 meters), the red light of the rear fog lights has strong penetration ability and is not easily scattered, allowing drivers behind to clearly identify the position of the vehicle in front at a relatively long distance (about 100 meters). The red design is specifically used for warning to prevent rear-end collisions.
Youdaoplaceholder0 Specifications for use with other lights
When visibility is between 100 and 200 meters: Fog lights, low beam headlights, side marker lights and taillights should be turned on simultaneously. The vehicle speed should be no more than 60km/h and the distance between vehicles should be no less than 100 meters.
When visibility is between 50 and 100 meters: vehicle speed ≤40km/h, vehicle distance ≥50 meters.
When visibility is less than 50 meters: Vehicle speed ≤20km/h. Pull over to the side of the road and turn on the hazard warning lights if necessary.
Youdaoplaceholder0 Advantage over hazard flash
The penetration power of the rear fog lights is much higher than that of the hazard warning lights (hazard lights), and turning on the hazard lights will mask the function of the turn signals, affecting the safety of lane changing. Therefore, fog lights should be given priority over hazard lights in bad weather.
Youdaoplaceholder0 Design principle and special structure
The left half of the light is semi-elliptical, while the right half contains horizontal lines and curves, enhancing the backscattering effect.
The installation position is close to the ground to reduce the interference of light scattering.
Youdaoplaceholder0 Summary : Rear fog lights are "safety messengers" in low visibility conditions, significantly reducing the risk of rear-end collisions by providing a continuous and stable red warning light. They should be used in accordance with vehicle speed, distance and other regulations.
Possible causes and solutions for rear fog lamp failure
Rear fog lamp malfunctions are usually caused by the following reasons. It is recommended to follow the sequence when troubleshooting:
Youdaoplaceholder0 Confirm normal design phenomenon : If only the left rear fog light is on and the right one is off, this is normal design as required by regulations (to avoid confusion with brake lights), not a malfunction. However, if the unilateral fog lamp that should be on does not light up, maintenance is required.
Youdaoplaceholder0 Check if the bulb is broken : Aging or burning of the bulb is the most common cause. Replace it with a bulb of the same specification. It can be confirmed through visual inspection or disassembly and assembly testing (reference case).
Youdaoplaceholder0 Check if the fuse has blown : The fuse in the fuse box corresponding to the rear fog lamp circuit may have blown due to overload. Replacing it with a fuse of the same amperage will restore it.
Youdaoplaceholder0 Troubleshoot line or switch faults :
Poor contact, short circuit or open circuit of the line requires inspection of the connection ports and wire harnesses, and repair of loose or damaged parts.
A damaged switch may cause the signal to fail to be transmitted. It is necessary to test the switch contacts or replace the assembly.
Youdaoplaceholder0 System false alarm or fault code residue : If the above hardware is normal, it may be a sensor false alarm or a software fault, and the fault code needs to be cleared with a professional diagnostic tool.
Youdaoplaceholder0 Hint :
When checking by yourself, give priority to inspecting easily replaceable parts (such as bulbs and fuses).
It is recommended that complex circuit problems be handled by professional technicians to avoid misoperation.
