What is a car cylinder gasket
Automobile cylinder gaskets (also known as cylinder gaskets) are elastic sealing elements installed between the engine cylinder block and the cylinder head. Their main function is to fill the microscopic pores at the interface between the two, ensuring the sealing of the combustion chamber and preventing the leakage of high-pressure gas, cooling water and engine oil.
Core function
Youdaoplaceholder0 Sealing function : By filling the gap between the cylinder block and the cylinder head, it prevents air leakage, water leakage and lubricating oil leakage from the cylinder, ensuring the normal operation of the engine.
Youdaoplaceholder0 High temperature and high pressure resistance : maintains elasticity in high-temperature and high-pressure environments, compensates for unevenness of the joint surface, and ensures sealing effect.
Common types
Youdaoplaceholder0 metal-asbestos material : covered with copper or steel sheet on the outside, it has good elasticity but relatively weak strength.
Youdaoplaceholder0 Solid metal sheet material : mostly used in high-performance engines, sealing is achieved by stamping convex patterns.
Youdaoplaceholder0 steel wire mesh or rubber skeleton material : combining asbestos and rubber to enhance sealing performance.
If the cylinder gasket is damaged, it may cause problems such as reduced engine power and insufficient cylinder pressure, and it needs to be replaced in time. However, it should be noted that replacement may affect the vehicle's residual value, and the maintenance cost and the vehicle's residual value need to be balanced.
The function of the cylinder gasket is as follows: The cylinder gasket is a sealing element between the top surface of the engine block and the bottom surface of the cylinder head. Its function is to keep the cylinder sealed without air leakage and to prevent the coolant and engine oil flowing from the engine block to the cylinder head from leaking. The cylinder gasket bears the pressure generated when the cylinder head bolts are tightened, and is subject to the high temperature and high pressure of the combustion gas inside the cylinder as well as the corrosion of the engine oil and coolant. The cylinder gasket should have sufficient strength and be pressure-resistant, heat-resistant and corrosion-resistant. In addition, it also needs to have a certain degree of elasticity to compensate for the roughness and unevenness of the top surface of the engine block and the bottom surface of the cylinder head, as well as the deformation of the cylinder head caused by the force of gas during engine operation. According to the different materials used, cylinder gaskets can be classified into various types such as metal-asbestos gaskets, metal composite material gaskets and all-metal gaskets. Both metal composite material gaskets and all-metal gaskets belong to asbestos-free cylinder gaskets. As there is no asbestos interlayer, the formation of airbags in the gasket can be eliminated, and industrial pollution can also be reduced. This is the current development direction.
The main manifestations of car cylinder gasket faults are abnormal power system, oil-water mixture and air leakage, etc. Timely maintenance is required to avoid engine damage.
Abnormal power system
The engine shakes violently and lacks power at low speeds, similar to a faulty spark plug that persists even after replacement. The power has dropped sharply. Even when the accelerator is fully depressed, it still feels weak. When the accelerator is pressed in third gear on a flat road, the engine speed rises but the vehicle speed lags behind, accompanied by a "putt-putt" sound.
The phenomenon of oil-water mixture
There are oil droplets floating in the radiator, abnormal consumption of antifreeze, emulsified substances (the mixture of oil and water appears milky white) on the oil cap. The oil level rises abnormally when the car is cold and drops when it is hot.
Air leakage and abnormal noise
When starting cold, a rhythmic air leakage sound (similar to a balloon deflating) appears near the intake pipe. The abnormal noise increases with the rise in engine speed and does not disappear after the vehicle is warmed up. If the damaged area is connected to the outside, a loud "pop pop" sound will be produced.
Abnormal water temperature
While driving, the water temperature gauge suddenly burst, but the radiator fan is operating normally. When the car is cold, if you open the radiator cap and step hard on the accelerator, coolant may gush out or bubbles may roll, which may be accompanied by white smoke coming out of the exhaust pipe.
The main reason for the cylinder gasket of a car to malfunction is the combined effect of engine overheating, cylinder gasket quality issues, bad driving habits, assembly problems and cooling system failures, which leads to seal failure.
Core cause analysis of
Engine overheating causes high-pressure shock
Long-term high-load operation (such as continuous high-speed driving) generates high temperature and high pressure, causing the metal layer of the cylinder gasket to be eroded.
Cooling system malfunctions (such as clogged radiator, fan failure, or insufficient coolant) can cause the engine to "boil over", accelerating the aging of the cylinder gasket.
Gasket quality and assembly defects
Using poor-quality cylinder gaskets with uneven thickness or unevenly wrapped asbestos.
When tightening the cylinder head bolts, the operation was not carried out in accordance with the standard torque, resulting in uneven force and gas leakage.
Abnormal mechanical condition
Excessive wear or breakage of the piston rings can cause scratches on the cylinder block.
The failure of the valve seal causes air leakage, which has a long-term impact on the pressure balance inside the cylinder.
Detailed explanation of the inducing factors of
Driving behavior affects
Driving aggressively without preheating in winter leads to uneven cold and hot stress in the cylinder block.
Frequent rapid acceleration causes the instantaneous peak pressure inside the cylinder to exceed the sealing limit.
Improper maintenance
The use of inferior fuel can cause knocking and impact the sealing surface of the cylinder.
Failure to replace the failed coolant in time led to corrosion of the cylinder block.
Ignoring the adjustment of ignition timing, abnormal combustion increases the heat load.
Design defect exception
Some models have batch quality issues with cylinder gaskets (recall information can be checked through the vehicle identification number).
