What is the left rear longitudinal beam assembly of the car?
The left rear longitudinal beam assembly is a longitudinal load-bearing beam structure of the vehicle's left rear side. It usually refers to the metal beam beneath the trunk floor and on the inner side of the left rear tire, which is part of the vehicle frame.
In simple terms, it is one of the core components of the vehicle's rear impact protection system, and its main functions are:
- Supporting the vehicle body: It forms a rigid frame together with crossbeams, bearing the weight of the vehicle and rear components.
- Collision energy absorption: In case of rear-end collisions or other accidents, it collapses and deforms to absorb the impact energy, protecting the passenger compartment as well as the fuel tank, battery pack, and other critical components.
From a structural and manufacturing perspective, it is mostly made of high-strength steel through stamping, with cross-sections in forms such as trough-shaped, I-shaped, or box-shaped. There are also lightweight solutions like integrated die-cast aluminum alloys.
Why it is worth paying attention to
If you are looking at used cars, repairing or evaluating accident vehicles, the left rear longitudinal beam is a key inspection point:
- Location: On the left and right sides of the spare tire compartment under the trunk floor, connecting to the rear bumper installation position. The left rear longitudinal beam is the left one.
- Accident judgment: If there are any cuts, welds, or repair marks here, it indicates that the vehicle's rear part may have experienced a significant impact.
- Maintenance considerations: Severely damaged rear longitudinal beams can be replaced, but it must be done using a professional beam alignment instrument in a fully equipped repair shop; the strength after repair cannot fully reach the original factory level.
- Value impact: The damage or repair history of the rear longitudinal beam will directly affect the valuation of a used car.
If you are considering purchasing a used car, it is recommended to focus on checking if there are any repair marks on the rear longitudinal beam, as this is related to the vehicle's safety and future value.
The left rear longitudinal beam assembly is a key structural component of the vehicle's body frame, mainly functioning to support the rear of the vehicle, bear weight, and absorb energy during rear-end collisions to protect the occupants.
Specifically, it has these core functions:
- Structural support: The longitudinal beam extends along the vehicle's longitudinal axis and works together with crossbeams to form the frame, ensuring the vehicle's rigidity and driving stability, while also bearing the impact from the wheels and the road surface.
- Collision protection: In case of severe rear-end collisions, the longitudinal beam collapses and deforms to absorb the impact energy, reducing the transfer of impact to the passenger compartment. It works in conjunction with anti-collision steel beams and energy absorption boxes - the energy absorption box collapses first, and then the longitudinal beam further absorbs the energy.
- Fixed installation points: The longitudinal beam has installation points for fixing important components such as the rear suspension, fuel tank, and exhaust pipe, ensuring the stable operation of these systems.
- Location identification: The rear longitudinal beam is located beneath the trunk floor and corresponds to the front longitudinal beam under the engine compartment, jointly protecting the safety of the passengers inside.
Note: If the rear longitudinal beam undergoes severe deformation or wrinkling in an accident, it generally requires cutting and replacement, and cannot be simply repaired with sheet metal work; otherwise, it will affect the strength and safety of the vehicle.
If the rear longitudinal beam is damaged, it is a damage to the vehicle's structural components. The handling method depends on the degree of deformation: minor deformation (bending angle less than 15°) can be corrected and repaired, but the strength will decrease, and it can only be restored to about 80% of the original factory level.
Severe deformation (folded, torn, or bent more than 30°) requires replacement. Even after cutting and welding, the strength cannot fully reach the original factory level.
Judgment criteria: A single point depression of 5mm or less without wrinkles and with a vehicle age of less than 8 years can be considered for repair; if there are multiple wrinkles or the bending length exceeds 20cm, it is more advisable to replace the beam directly.
Baidu Encyclopedia
Several key reminders:
The longitudinal beam is a core component for bearing the vehicle's rigidity and absorbing collision energy. Whether repaired or replaced, it will affect the safety of a secondary collision and the vehicle will be classified as an accident vehicle, with a residual value typically reduced by 15%-30%.
The repair must be carried out at a qualified and well-equipped regular 4S store or a first-class repair shop. Use a beam alignment instrument for positioning, and use carbon dioxide gas shielded welding for welding. After the repair, perform four-wheel alignment.
Before the repair, have the insurance company assess the damage. Refer to the assessment report and the suggestions from third-party testing to determine the plan. Don't force repair of severely deformed longitudinal beams just to save money.
If the repair cost exceeds 30% of the current value of the vehicle, or if the vehicle age is close to the scrap age limit, it is recommended to assess whether it is still necessary to repair.
