The rear components of the car floor panel
The rear components of the car floor panel are structural components (not decorative pedals), with the core functions being collision safety and structural load-bearing:
Side impact protection: As a key part of the rear section of the floor beam, it absorbs and disperses impact energy during a side collision, limiting the intrusion of the passenger compartment and protecting rear passengers and the battery pack (for electric vehicles).
Force transmission path construction: It forms a continuous box-shaped cavity with the front floor panel, conducting lateral impact force backward to the C-pillar/ rear chassis frame, achieving uniform force dispersion throughout the vehicle.
Structural rigidity support: It connects the floor with the bottom frame of the vehicle, resisting driving distortion stress and maintaining the vehicle's torsional stiffness; some designs integrate sliding door guide rail installation interfaces (such as MPVs/ some SUVs).
Note: Do not confuse with "welcome step/ floor guard plate" - the latter is an exterior decorative component, only for anti-scuffing and beautification, without structural safety functions. The rear components of the floor panel are located inside the car door and are an original factory welded structure, not removable or modifiable.
(Reference: Patent CN117429510A describes the "U-shaped + reinforcement plate" closed structure of the rear floor panel; the GBTC crash test standard requires the force transmission logic of the floor beam; the integrated design specification for battery protection in electric vehicles)
Core judgment: The rear components of the floor panel belong to the vehicle's structural components (not decorative panels), involving safety and sealing. DIY repair is strictly prohibited; it must be handled by a professional body shop/body correction workshop.
First, confirm the nature of the damage
Structural damage (indentation, cracking, rusted perforation, weld point fracture): Affects the rigidity of the vehicle and collision energy absorption, requires "cutting and replacement or frame correction + gas protection welding + anti-rust painting".
Only decorative panel detachment/clip fracture (plastic guard plate): Can try to reset or replace the clip; if the clip position is damaged, a special replacement part + hot melt adhesive assistance fixation (non-structural adhesion) is required.
Note: "Rear components of the floor panel" usually refer to the metal floor panel (welded to the floor), not detachable plastic floor trim - misjudgment will lead to safety hazards.
Professional repair process (performed by technicians)
Evaluation and disassembly
Remove the inner lining of the rear fender, seats, carpets, etc., to expose the damaged area;
Check if it affects the floor reinforcement beam, floor crossbeam or wiring/airbag sensors.
Repair plan selection
Mild deformation (<10mm): Subframe pulling + fire shaping;
Severe deformation/cracking: Cut the damaged section → Make a matching new panel → Inert gas protection welding → Stress release hammering;
Rust perforation: Thoroughly remove rust to the metal color → Welding/patching → Double-layer anti-rust primer + topcoat color spraying.
Key acceptance items
Size matching (laser measurement of door frame gap/ diagonals);
Sealing test (water spray + air pressure leak detection); - Integrity of anti-corrosion coating (electrophoretic primer + intermediate coat + topcoat).
Risk warning
Self-welding/knocking can cause stress concentration, paint blistering, sealing failure, leading to water leakage, abnormal noise, and even structural failure during a collision;
Insurance claims require a 4S store or first-class repair shop damage assessment form; non-formal repairs may be denied coverage.
Suggestion: Contact a repair shop with "body correction qualification" (preferably 4S store or large chain body shop center) immediately to obtain the original factory repair manual guidance. If it is only a plastic trim issue, take photos to confirm the component number and purchase the original factory replacement part for self-installation.
